SPOOLOGIC Hx35 Stage 2 Turbocharger
94-02 5.9L Dodge Cummins 6BT ISB 12V 24V
Boost performance up to 60 RWHP for stock trucks 650+ RWHP Peak for trucks with fuel system modifications and custom tuning when you install a Spoologic HX35 Stage 2 Turbo. This turbo is capable of producing 40PSI of boost along with quick spool-up and a wide torque curve for more power across the entire RPM range. This is a direct drop-in, bolt-on replacement. Plus, it boasts exclusive features that give you greater all-around performance and durability making it the perfect turbo for everything from daily driving to extreme towing.
Data-driven design is at the heart of Spoologic Turbos, including extensive testing in the lab, on the bench, on the track, and on the street. That data is applied to the design and manufacture of every component. Spoologic does not buy third-party parts for its turbos. Every component is custom made according to Spoologic’s demanding specifications.
- Larger Turbo Assembly
Lowers drive pressure creating a better balance between boost and drive pressure. This improved balance under heavy load means more efficiency and power at any given boost level, plus lower EGTs under heavy load providing an improvement in overall peak power.
- Custom Designed and Manufactured Wheels
Unlike other brands that simply buy wheels from third parties, Spoologic turbos feature lightweight billet wheels that are custom designed and built to Spoologic specifications.
- Custom Cast Cover with Drilled Anti-surge Ring
Removes the dreaded turbo surge “hic-up” allowing for smoother rapid acceleration.
- Larger Compressor Wheel Assembly
The Spoologic HX35 features a 63mm Inducer and a 93mm Exducer.
- Larger Turbine Shaft
The Turbo features a 76mm Inducer on the turbine shaft along with the 64mm Exducer which together produce maximum airflow for maximum performance.
- Upgraded Waste Gate Actuator
Blow-off pressure set at 40psi.
- Port Matched Exhaust Inlets
Reduces turbulence giving you maximum drive pressure.
- Custom Designed High Flow Ported Turbine Housing
Gets used exhaust gas out of the turbo more quickly allowing for faster induction of fresh cold air and lower EGT’s.
- Ceramic Coated Center Section and Turbine Housing
Reduces ‘turbo lag’ or ‘spool’ time by keeping the turbine inlet gases hot while reducing underhood temperatures up to 70 degrees which increases engine performance and lifespan.
- All-New Units, Not Remanufactured.
Providing you many more years of reliable performance and peace of mind.
- 360-degree Thrust Bearings
Drastically extends the life and reliability of the turbo.
- Step Gap Oil Seal
Provides tighter tolerances for superior sealing
Each component is balanced independently, then the entire rotating assembly is speed VSR speed balanced, ensuring perfect performance and maximum dependability.
- Backed by a 48-Hour Warranty Repair Guarantee
Need warranty work? We’ll repair and ship your turbo within 48-hours of receiving it in our warehouse.
- Direct Drop in Bolt-On Replacement
Nothing else needed. Saves you time and money.
Available in different colors:
